TT100 In-Line Viscometer Installation, Operation, Maintenance and Service Instructions
P/N M/97-520 3-13
19. Reconnect the milliampere cable to J1 Pins 1 and 2 on the torque
sensor electronics circuit board and install the enclosure cover.
CAUTION
Handle the sensing endcap assembly with care when installing it into the
measuring chamber. Damage to the torsion element may result by
contacting the stator with the rotor.
20. Remove the sensing endcap from the vise and carefully install it
into the viscometer.
21. Install the sensing endcap mounting bolts and tighten them in a
rotational pattern.
22. Turn power ON to the torque sensor electronics enclosure.
CAUTION
Do not run the motor without fluid in the viscometer. Damage to the
mechanical seals may result.
