TT100 In-Line Viscometer Installation, Operation, Maintenance and Service Instructions
P/N M/97-520 6-21
Figure 6-11:Drive Endcap Removal
SENSING ENDCAP
ASSEMBLY
MEASURING CHAMBER
DRIVE ENDCAP
ASSEMBLY
O-RING
O-RING
