TT100 In-Line Viscometer Installation, Operation, Maintenance and Service Instructions
P/N M/97-520 6-31
Figure 6-14: Drive Endcap Disassembly (with Double Mechanical Seal)
DOUBLE MECHANICAL SEAL
MOUNTING SCREWS
DOUBLE MECHANICAL SEAL ASSEMBLY
DRIVE ENDCAP
DRIVE SHAFT
ROTOR
ROTOR MOUNTING SCREWS
O-RING
DRIVE SHAFT COUPLING
O-RING
