Brother MFC-7365DN

3-84
Confidential
(6) Remove the two taptite pan B M4x14 screws to remove the fuser unit.
Fig. 3-71
Note:
• Do not apply a physical impact or vibration to the fuser unit.
• Do not touch the roller and electrodes as shown in the figure below to prevent
breakage of the fuser unit.
Roller
Taptite pan B M4X14
Fuser unit
