3-87
Confidential
(9) Remove the low voltage power supply PCB ASSY, and disconnect the three connectors
from the rear side.
(10) Remove the LV insulation sheet.
Fig. 3-75
Low voltage power
supply PCB ASSY
LV insulation sheet
Connectors
