Brother MFC-7365DN Service Manual

1-2
Confidential
Specifications are subject to change without notice.
Model
DCP-7055
DCP-7055W
DCP-7057
DCP-7057E
DCP-7057W
DCP-7060D DCP-7065DN
DCP-7070DW
HL-2280DW
Noise Level Sound pressure Printing: 53 dB (A)
Ready: 30 dB (A)
Sound power Printing:
6.60 B (A)
Ready:
4.30 B (A)
For U.S.A.
/China
Printing:
6.74 B (A)
Ready:
4.30 B (A)
Except for
U.S.A.
/China
Printing:
6.40 B (A)
Ready:
4.27 B (A)
For U.S.A.
Printing: 6.81 B (A)
Ready: 4.30 B (A)
Except for U.S.A.
Printing: 6.40 B (A)
Ready: 4.22 B (A)
Environment Temperature Operating: 10 to 32.5 °C
Storage: 0 to 40 °C
Humidity Operating: 20 to 80 %
Storage: 10 to 90 %
Dimensions
(W x D x H)
Carton Size For models with ADF :
527 x 510 x 493 mm (20.8 x 20.1 x 19.4 inch)
For models without ADF :
527 x 510 x 440 mm (20.8 x 20.1 x 17.4 inch)
Machine Size For models with ADF :
405 x 398.5 x 316 mm (15.95 x 15.7 x 12.45 inch)
For models without ADF :
405 x 398.5 x 268 mm (15.95 x 15.7 x 10.6 inch)
Weights With Carton
12.9 kg / 28.4 lb 13.2 kg / 29.1 lb 14.6 kg / 32.2 lb For U.S.A.
12.6 kg / 27.8 lb
Except for
U.S.A.
13.4 kg / 29.5 lb
Without Carton,
With toner/drum
9.8 kg / 21.6 lb 10.1 kg / 22.3 lb 11.4 kg / 25.1 lb 10.3kg / 22.7 lb
Without Carton
and toner/drum
8.6 kg / 19.0 lb 8.9 kg / 19.6 lb 10.2 kg / 22.5 lb 9.1 kg / 20.1 lb
LCD Size Except for China: 16 Characters x 2 lines
For China: 10 Characters x 2 lines

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
