Brother MFC-7365DN Service Manual

1-3
Confidential
Specifications are subject to change without notice.
Model MFC-7360
MFC-7360N
MFC-7362N
MFC-7365DN
MFC-7460DN
MFC-7470D
MFC-7860DN
MFC-7860DW
Print method Electrophotographic / Laser
Resolution 600 dpi x 600 dpi, HQ1200 (2400 X 600 dpi) quality
Print speed Up to 24/24 ppm For MFC-7365DN
Up to 24/24 ppm
Except for MFC-7365DN
Up to 26/27 ppm
* When loading A4 or Letter-size paper from the paper
tray.
Warm-up time From Sleep Mode: Less than 7seconds
* At 23°C (73.4F)
From Power OFF → ON:
Less than 27 seconds
From Power OFF → ON
For MFC-7365DN/7460DN
Less than 27 seconds
Except for MFC-7365DN/
7460DN
Less than 28 seconds
* At 23°C (73.4F)
First print time
From Ready mode Less than 8.5 seconds
From Sleep mode Less than 16.5 seconds
CPU ARM9 200MHz
Memory 16 MB 32 MB
Backup Clock Up to 2 hours For MFC-7365DN/7460DN
Up to 2 hours
Except for MFC-7365DN/
7460DN
Up to 60 hours
Interface Hi-Speed
USB 2.0
For MFC-7470D
Hi-Speed USB 2.0
Except for MFC-7470D
Hi-Speed USB 2.0,
Ethernet 10/100 BASE-TX
Hi-Speed USB
2.0, Ethernet
10/100 BASE-
TX,
IEEE802.11b/g
(Infrastructure
Mode / Adhoc
Mode)
Power
Consumption
* Measured with
only USB
connected
Peak 1080 W
Copying Average: Approximately 445 W
Ready Average: Approximately 55 W
Sleep, Wireless
LAN: ON
N/A Average:
Approximately
3.9 W
Deep Sleep Average: Approximately 1.5 W Average:
Approximately
1.7 W

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
