Brother MFC-7365DN Service Manual

1-4
Confidential
Specifications are subject to change without notice.
Model MFC-7360
MFC-7360N
MFC-7362N
MFC-7365DN
MFC-7460DN
MFC-7470D
MFC-7860DN
MFC-7860DW
Noise Level Sound pressure Printing: 53 dB (A)
Ready: 30 dB (A)
Sound power Printing: 6.74 B (A)
Ready: 4.30 B (A)
For Europe/
Oceania
Printing:
6.40 B (A)
Ready:
4.22 B (A)
Except for
Europe/
Oceania
Printing:
6.81 B (A)
Ready:
4.30 B (A)
For U.S.A.
Printing:
6.81 B (A)
Ready:
4.30 B (A)
Except for
U.S.A.
Printing:
6.40 B (A)
Ready:
4.22 B (A)
Environment Temperature Operating: 10 to 32.5 °C
Storage: 0 to 40 °C
Humidity Operating: 20 to 80 %
Storage: 10 to 90 %
Dimensions
(W x D x H)
Carton Size For models without Handset:
527 x 510 x 493 mm (20.8 x 20.1 x 19.4 inch)
For models with Handset:
573 x 510 x 493 mm (22.6 x 20.1 x 19.4 inch)
Machine Size For models without Handset:
405 x 398.5 x 316 mm (15.95 x 15.7 x 12.45 inch)
For models with Handset
:
477 x 398.5 x 316 mm (18.8 x 15.7 x 12.45 inch)
Weights With Carton For Asia:
14.5 kg / 32.0 lb
For China:
15.1 kg / 33.3 lb
14.6 kg / 32.2 lb
For models without Handset:
14.8 kg / 32.6 lb
For models with Handset:
15.4 kg / 34.0 lb
Without Carton,
With toner/drum
For Asia:
11.3 kg / 24.9 lb
For China:
11.7 kg / 25.8 lb
11.4 kg / 25.1 lb
For models without Handset:
11.6 kg / 25.6 lb
For models with Handset:
11.9 kg / 26.2 lb
Without Carton
and toner/drum
For Asia:
10.1 kg / 22.3 lb
For China:
10.4 kg / 22.9 lb
10.2 kg / 22.5 lb
For models without Handset:
10.4 kg / 22.9 lb
For models with Handset:
10.6 kg / 23.4 lb
LCD Size Except for China: 16 Characters x 2 lines
For China: 10 Characters x 2 lines

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
