Brother MFC-7365DN Service Manual

2-49
Confidential
■ Error code 85
These errors do not usually occur in the normal use. The conceivable causes are noise around
the installation site, fluctuation of the power supply voltage, and failures in the software.
Error, which cannot be specified, occurs.
Error code 86
Error, which cannot be specified, occurs.
Error code 87
Error, which cannot be specified, occurs.
■ Error code 88
Paper jam inside the machine.
No Tray
A Tray is not detected, install #T.
No Tray
A Tray is not detected, install #T.
---
<User Check>
• Turn OFF the power switch, and turn it ON again after a while.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Jam Inside
Open the Front Cover, pull out the Drum Unit completely and remove
the jammed paper.
<User Check>
• Check if the paper is jammed. If jammed, remove it.
Step Cause Remedy
1
Harness connection failure of
paper eject sensor PCB ASSY
Check the harness connection of the paper
eject sensor PCB ASSY and reconnect it.
2
Paper eject actuator catching on
some position
Correct the position of the paper eject
actuator.
3
Paper eject sensor PCB failure Replace the paper eject sensor PCB
ASSY.
4 Fuser unit gear damaged Replace the Fuser unit.
5 Main PCB failure Replace the main PCB ASSY.

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
