Brother MFC-7365DN Service Manual

2-50
Confidential
■ Error code 89
Check that the paper smaller than the specified size is not loaded.
■ Error code 8A
Paper jam at the paper tray and the front cover.
Size Error DX
Specify the correct paper and press Start.
<User Check>
• Use the A4 or Letter size paper.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Jam Tray
Remove the jammed paper from Tray, then press Start.
<User Check>
• Check if the paper is jammed at the paper tray and the front cover.
• Adjust the paper guide corresponding to the paper size.
• Check if the thickness of the paper is 60 to 105 g/m
2
.
• Check if too much paper is loaded in the tray.
Step Cause Remedy
1
Paper edge actuator catching on
some position
Correct the position of the paper edge
actuator.
2
Registration front actuator
catching on some position
Correct the position of the registration front
actuator.
3
Harness connection failure of
registration front/rear sensor PCB
ASSY
Check the harness connection of the
registration front/rear sensor PCB ASSY
and reconnect it.
4 Paper feeding kit worn out Replace the paper feeding kit.
5
High voltage power supply PCB
failure
Replace the high voltage power supply
PCB ASSY.
6
Registration front/rear sensor PCB
failure
Check the registration front/rear sensor
performance following the procedure
described in "Function code 32". If any
problem occurs, replace the regist frame
ASSY.

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
