Brother MFC-7365DN Service Manual

2-57
Confidential
■ Error code A4
The ADF cover is open.
■ Error code A5
Scanning failure upon FAX transmission. (Scanning unit failure for the first time.)
■ Error code A6
Scanning failure upon FAX transmission. (Scanning unit failure for the second time or later.)
Cover is Open
Close the ADF Cover.
<User Check>
• Close the ADF cover.
Step Cause Remedy
1
Coming off of document detection
actuator/ADF cover open actuator
Re-assemble the document detection
actuator/ADF cover open actuator.
2
Harness connection failure of
document detection sensor/ADF
cover open sensor PCB
Check the harness connection of the
document detection sensor/ADF cover
open sensor PCB and reconnect it.
3
Deformation and/or breakage of
ADF cover
Replace the ADF cover ASSY.
4
ADF cover open sensor failure Replace the document detection sensor/
ADF cover open sensor PCB ASSY.
5 Main PCB failure Replace the main PCB ASSY.
Scan Unable A5
Remove the original document. Turn the power off, then on again.
<User Check>
• Turn OFF the power switch, and turn it ON again after a while.
Scan Unable A6
See Troubleshooting and routine maintenance chapter in User's Guide.
Step Cause Remedy
1
White level data failure Execute the "Acquisition of white level data
(Function code 55)".
2 CIS unit failure Replace the CIS unit.
3 Main PCB failure Replace the main PCB ASSY.

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
