Brother MFC-8480DN Service Manual

7-15
Confidential
WSW34 Function setting 12 App. 1-35
WSW35 Function setting 13 App. 1-35
WSW36 Function setting 14 App. 1-36
WSW37 Function setting 15 App. 1-37
WSW38 V.34 transmission settings App. 1-38
WSW39 V.34 transmission speed App. 1-39
WSW40 V.34 modem settings App. 1-40
WSW41 ON-duration of the scanning light source App. 1-42
WSW42 Internet mail settings App. 1-43
WSW43 Function setting 16 App. 1-43
WSW44 Speeding up scanning-1 App. 1-44
WSW45 Speeding up scanning-2 App. 1-45
WSW46
Monitor of power ON/OFF state and parallel port kept at
high
App. 1-46
WSW47 Switching between high- and full-speed USB App. 1-47
WSW48 USB setup latency App. 1-48
WSW49 End-of-copying beep and print in black App. 1-48
WSW50 SDAA settings (Not used) App. 1-49
WSW51 Function setting 17 App. 1-49
WSW52 Function setting 18 App. 1-50
WSW53 Function setting 19 App. 1-50
WSW54 Function setting 20 App. 1-51
WSW55 Not used App. 1-52
WSW56 Function setting 21 App. 1-53
WSW57 Function setting 22 App. 1-54
WSW58 Function setting 23 App. 1-54
WSW59 Function setting 24 App. 1-55
WSW60 Not used App. 1-56
WSW61 Scanning light intensity to judge to be stable 1 App. 1-57
WSW62 Scanning light intensity to judge to be stable 2 App. 1-58
WSW63 Not used App. 1-59
WSW64 Setting the language / Default paper size App. 1-60
WSW65 Setting the paper support App. 1-60
WSW66 Drum life end App. 1-61
WSW67 Not used App. 1-61
WSW68 Fuser unit life end App. 1-61
WSW69 Document scanner unit life end App. 1-61
WSW70 Paper feeding kit life end App. 1-61
WSW71 Paper feeding kit 2 life end App. 1-61
WSW72 Paper feeding kit MP life end App. 1-62
WSW73 Not used App. 1-62
WSW74
The limited number of the documents in order for paper
ejection of the simplex scanning from ADF.
App. 1-62
WSW75 Paper eject distance of switch back App. 1-63
WSW No. Function Refer to:

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
