Brother MFC-L8850CDW Service Manual

2-94
Confidential
■ Paper jam at the MP tray
< User Check >
- Check if the paper is loaded into the MP tray correctly.
- Turn back the paper loaded in the MP tray or change the orientation of the paper by 180°.
- Adjust the paper guide corresponding to the paper size.
- Check if too much paper is loaded in the tray.
- Check if the thickness of the paper is 60 to 163 g/m
2
.
- Fan the stack of paper well and reinsert the papers into the paper tray.
■ Paper jam at the paper feeding section at the center of the machine
< User Check >
- Check if the paper is loaded into each paper tray correctly.
- Turn back the paper loaded in each paper tray or change the orientation of the paper by 180°.
- Adjust each paper guide in accordance with the paper size.
- Check if too much paper is loaded in the tray.
- Check if the thickness of the paper is 60 to 105 g/m
2
.
- Fan the stack of paper well and reinsert the papers into each paper tray.
- Check that the belt unit is properly set.
- Replace the drum unit.
- Replace the belt unit.
Step Cause Remedy
1 Foreign object around MP tray Remove the foreign object.
2 MP registration front actuator
coming off
Re-assemble the MP registration front
actuator.
3 Connection failure of the MP
registration front sensor PCB
harness
Reconnect the MP registration front
sensor PCB harness.
4 MP paper empty/registration
front sensor failure
Replace the MP paper empty/registration
front sensor PCB ASSY.
5 Main motor failure Replace the process drive unit.
6 Paper feed unit failure Replace the paper feed unit.
7 Fuser unit damaged Replace the fuser unit.
8 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 Foreign object inside machine Remove the foreign object.
2 Eject actuator coming off Re-assemble the eject actuator.
3 Fuser cover installation failure Re-assemble the fuser cover.
4 Connection failure of the eject
sensor PCB harness
Reconnect the eject sensor PCB harness.
5 Eject sensor failure Replace the eject sensor PCB ASSY.
6 Fuser drive gear Z25 damaged Replace the fuser drive gear Z25.
7 Main motor or process motor
failure
Replace the process drive unit.
8 Fuser unit failure Replace the fuser unit.
9 Main PCB failure Replace the main PCB ASSY.
