Fig. 3-19

Harness routing: Refer to “ Eject Sensor PCB ASSY, Fuser Unit”

Note:

- Do not apply a physical impact or vibration to the Fuser unit.

- Do not touch the roller and electrodes as shown in the figure below to prevent breakage

of the Fuser unit.

Fuser unit
