7-2

Confidential

2. PERIODICAL REPLACEMENT PARTS

2.1 Procedures to Replace Periodical Replacement Parts

■

Preparation

Prior to proceeding with the disassembly procedure,

(1) Unplug

-the AC cord,

- the telephone line,

- the USB flash memory,

- the USB cable, if connected, and

- the LAN cable, if connected.

(2) Remove the Paper tray.

Main body

Paper tray
