Safety Barrier Assembly Installation (Optional)
36 H148850_3_003
7.2 Safety Barrier Assembly
When positioning the acrylic walls begin with the back segment.
Step 1: While one person holds the acrylic wall steady, secure with two 6-32x0.625 PHPH,
Bag A, screws.
Ensure that the cables and tubing connected fit in the opening of the back panel and do not
get pinched during assembly.
