BTEK T419S Service Manual

T419S Indicator Service Manual 107
Note for 253 & 254: If an optional parameter is not specified, it the result is the same as if [N1] was specified.
The setpoint numbers must be in the following ranges: ‘N’ or ‘n’: 1 – 64 [N1] – [N64]
[N1] – print the state of a single setpoint. Prints as either “on” or “off”
[n1] – print the state of a single setpoint. Prints as either “1” or “0”
[B1] – print the state of a bank of setpoints. A single character is printed (0x00 – 0xFF) and represents the states of a group of 8 setpoints.
[b1] – print the state of a bank of setpoints. Two characters are printed for each bank “00” to “FF”. This is a text representation of the bank states.
Table 11.1 Optional Parameter (A0-A23)
A0 = 0.00001
A1 = 0.00002
A2 = 0.00005
A3 = 0.0001
A4 = 0.0002
A5 = 0.0005
A6 = 0.001
A7 = 0.002
A8 = 0.005
A9 = 0.01
A10 = 0.02
A11 = 0.05
21 SMOTSTR Sets values for Motion TRUE / FALSE sSPCMot
STRING (cont.) Applies to tokens 21-27 only
Using these tokens requires use of the required parameter [tXXfYY] where XX and YY represent the ASCII
hex character (1-255) to be sent for a true or false condition respectively. The XX or YY must be entered as
individual decimal values.
Example: To send a "1" for true or "0" for false condition the parameter would be entered as [116 52 57 102
52 56] in the Print Format Editor.
22 SCZSTR Sets values for Center of Zero TRUE / FALSE sSPCCZ
23 SOLDSTR Sets values for Overload TRUE / FALSE sSPCOld
24 SULDSTR Sets values for Underload TRUE / FALSE sSPCUld
25 SGPOL Sets values for Gross Polarity sSPCGPol
26 SNPOL Sets values for Net Polarity sSPCNPol
27 SAPOL Sets values for Active Value Polarity sSPCAPol
500 NULL Null NULL
Undefined
501 SOP Start Optional Parameters SOP [
502 EOP End Optional Parameters EOP ]
600 TEXT Print Data is Text Data Type Text “<ESC>txt”
601 PCL Print Data is Printer Control Language Data Type PCL “<ESC>PCL”
602 EPPOS Print Data is Epson Point of Sale Data Type Epson Pos “<ESC>EPS”
603 ZEBRA Print Data is Zebra Language Data Type Zebra “<ESC>ZEB”
604 RAW Print Data is RAW Data Type RAW “<ESC>raw”
650 BOLD Print Format Bold Format Bold “<ESC><ESC>B”
651 ITAL Print Format Italic Format Italic “<ESC><ESC>I”
652 UNDR Print Format Underline Format Underline “<ESC><ESC>U”
653 LAND Print Format Landscape Format Landscape “<ESC><ESC>L”
654 FF Print Format Form feed Format Form Feed “<ESC><ESC>F”
655 WRAP Print Format Line Wrap Format Line Wrap “<ESC><ESC>W”
Token Token Description of Value Name Value Data Type Parameter Name Optional Parameter Available Values
T.x T.x.1 T.x.2 T.x.3
A12 = 0.1
A13 = 0.2
A14 = 0.5
A15 = 1
A16 = 2
A17 = 5
A18 = 10
A19 = 20
A20 = 50
A21 = 100
A22 = 200
A23 = 500
