h. Create class map (op4)
 create rule 1: match p-bit 4, match-dscp af33
2. Create policy maps and add policies.
a. Create policy map (mix)
 create policy 1, class map (mix1), set P-bit 1
 create policy 2, class map (mix2), set P-bit 2, rate-limit 15, max burst size 4
 create policy 3, class map (mix3), set P-bit 3
 create policy 4, class map (mix4), set P-bit 4
 create policy 5, class map (mix5), set P-bit 5
 create policy 6, class map (mix6), set P-bit 6
 create policy 7, class map (mix7), set P-bit 7, rate-limit 10, max-burst size 4
b. Create policy map (0p4)
 create policy 1, class map (0p4), set P-bit 3
3. Add policy maps to Ethernet interfaces.
 1/x3 policy map (mix)
 2/x3 policy map (mix)
 2/g4 policy map (0p4)
Related topics
 Creating a Class Map and Rules (on page 90)
 Creating a Policy Map and Policies (on page 93)
