 If parameters specified in the first-applied template are not specified in the last-applied
template, the values are retained from the first-applied template for those parameters.
DSL port parameters for data and video services
DSL Port
Category
Parameter Data Service Video Service
Basic
Service Type
vdsl2 (or adsl2+)
vdsl2 (or adsl2+)
VDSL2 Profile
17a (auto for adsl2+)
17a (auto for adsl2+)
Downstream Min Rate
384
384
Downstream Max Rate
100000
100000
Upstream Min Rate
384
384
Upstream Max Rate
100000
100000
Downstream Min Impulse Noise Protection*
0.5
2
Upstream Min Impulse Noise Protection
0.5
0.5
Downstream Interleave Max Latency*
5
8◊
Upstream Interleave Max Latency
5
5
Downstream Min SNR*
0
2
Downstream Max SNR*
10
16
Downstream Target SNR*
5
8
Upstream Min SNR*
0
2
Upstream Max SNR*
10
16
Upstream Target SNR*
5
8
Advanced
PTM Override
auto
auto
ATM Header Compression
enabled
enabled
Downstream Rate Adaption Mode
dynamic
dynamic
Upstream Rate Adaption Mode
dynamic
dynamic
Downstream Downshift Rate Adaption Margin*
2
5
Downstream Upshift Rate Adaption Margin*
6
9
Upstream Downshift Rate Adaption Margin*
2
5
Upstream Upshift Rate Adaption Margin*
6
9
Downstream Downshift Rate Adaption Time
30
30
Downstream Upshift Rate Adaption Time
30
30
Upstream Downshift Rate Adaption Time
30
30
Upstream Upshift Rate Adaption Time
30
30
Downstream Enhance Impulse Noise Protection
phyr
phyr
Upstream Enhance Impulse Noise Protection
phyr
phyr
*Different DSL template parameter values are recommended for data and video services
◊ 8 ms with MMR, or 20 ms without MMR.
For CLI:
set dsl-template bp_data basic service-type vdsl2 vdsl-profile 17a
description bp_data ds-min-rate 384 ds-max-rate 100000 us-min-rate
384 us-max-rate 100000 ds-min-inp 0.5 us-min-inp 0.5 ds-intrlv-max-
latency 5 us-intrlv-max-latency 5 ds-min-snr 0 ds-max-snr 10 ds-
target-snr 5 us-min-snr 0 us-max-snr 10 us-target-snr 5 admin-state
enabled
