Parameter Description Valid Options
Update TDM Gateway IP Host
ID Name of the IP Host to use for the voice services provisioned on the
VDSL2 card.
An existing IP Host
Host Protocol Host protocol for the SIP client. If you select "static," you must also
enter a static IP address, mask, and gateway addresses.
static
dhcp ‡
Static IP If the host protocol is static, the IP address statically assigned to the
VDSL2 card. This attribute is ignored, yet preserved, if the host protocol
is later switched to DHCP.
4-byte IP address
Static IP Mask If the host protocol is static, the IP network mask assigned to the VDSL2
card. This attribute is ignored, yet preserved, if the host protocol is later
switched to DHCP.
4-byte IP address
Static IP Gateway If the host protocol is static, the Static IP gateway address for the
VDSL2 card to use in routing its traffic to the SIP server. This attribute is
ignored, yet preserved, if the host protocol is later switched to DHCP.
4-byte IP address
S-VLAN (Outer Tag)
*
Outer tag VLAN ID (customer-specific) for the service tag action to
reference.
2-4093
(Except for 1002-1005
which are reserved for E-
Series operation.)
*Required fields
‡ Default
To create a TDM gateway service
1. On the Navigation Tree, click the Voice port on which you want to add a SIP service.
2. In the Work Area, click Services > Table > Create > TDM Gateway Service to open
the Create dialog box.
3. Reference the table above to configure the parameters.
4. Click Create to activate a TDM Gateway voice service on the subscriber port.
5. Click Provisioning to verify the service operation.
For CLI:
add tdm-gw-svc to-pots-port <pots port> ip-host <card ip> tdm-gw-
profile <profile name> crv <crv> [admin-state]
Example CLI:
add tdm-gw-svc to-pots-port 1/1 ip-host 1/tdmgw tdm-gw-profile tdmgw
crv N1-1-IG1-1
Creating an H.248 Service
This topic describes how to configure H.248 gateway voice service on a VDSL2 card Voice
(POTS) port. Each VDSL2 card can only support one voice service type, either SIP, TDM
gateway, or H.248 gateway.
