Page #207 background image
207
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Parameter Description Valid Options
Update SIP IP Host
ID Name of IP Host to use or update, or indicate the creation of a new
IP Host.
Any established IP host
for the card
Host Protocol Host protocol for the SIP client. If you select "static," you must also
enter a static IP address, mask, and gateway addresses.
If you set the Host Protocol to dhcp, any previously set Static-IP,
Static IP Mask, and Static IP Gateway addresses are ignored, yet
preserved. The DHCP host configuration occurs when the first
POTS port is configured.
static
dhcp
S-VLAN (Outer Tag)
*
Indicates the customer-specific tag. 2-4093
(Except for 1002-1005
which are reserved for
E-Series operation.)
Name* If you are creating a new IP host, enter a descriptive name for it.
This field will auto-fill if you select a previously configured IP host.
Character string up to
31 characters.
Static IP If the host protocol is static, IP address statically assigned to the
VDSL2 card. This attribute is ignored, yet preserved, if the host
protocol is later switched to DHCP. The static IP address must not
be the same as the gateway address.
4-byte IP address
Static IP Mask If the host protocol is static, IP network mask assigned to the
VDSL2 card. This attribute is ignored, yet preserved, if the host
protocol is later switched to DHCP.
4-byte IP address
Static IP Gateway If the host protocol is static, the Static IP gateway 4-byte address
to use in routing its traffic to the SIP server. This attribute is
ignored, yet preserved, if the host protocol is later switched to
DHCP. The gateway address and subtending IP addresses must
belong to the same subnet, as indicated by the mask
4-byte IP address
*Required fields
‡ Default
To create a SIP voice service
1. On the Navigation Tree, click the Voice port on which you want to add a SIP service.
2. In the Work Area, click Services > Table > Create > SIP Service to open the Create
dialog box.
3. Reference the table above to configure the parameters.
4. Click Create to activate a SIP voice service on the subscriber port.
5. Click Provisioning to verify the service operation.
For CLI:
add sip-svc to-pots-port <vdsl-port> ip-host <lc-ip> sip-gw-profile
<sipgw-profile> user <user name> password <pswd> uri <URI ID> [call-
waiting|caller-id|three-way-calling|t38-fax-relay|dial-plan|admin-
state|direct-connect|direct-connect-timer|msg-waiting-indicator]
Example CLI:
add sip-svc to-pots-port 2/1 ip-host 2/SIP_IPhost sip-gw-profile
SIP_gw user 2012042453 password password uri 2012042453
