Calix E3-48C User Manual

138
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Parameter Description Valid Options
Min Expected Throughput
Rate
With G.INP, we use downstream/upstream Min Expected
Throughput Rate (MINETR) and Max Net Data Rate (MAXNDR).
MAXNDR must be configured higher than MINETR to account for
retransmission bandwidth overhead.
Downstream or upstream minimum effective throughput (Kbps, in 1
Kbps increments). Roughly equivalent to minimum train rate when
using interleaving.
 Variable rate, but fixed at train-up:
For G.INP, set MINETR < MAXNDR and set rate adapt mode
to init. This is similar to the fixed rate case.
 Variable, dynamic rate:
For G.INP, set MINETR < MAXNDR and set rate adapt mode
to dynamic
32-512000
32 ‡
Max Net Data Rate Downstream or upstream maximum net data rate (Kbps, in 1 Kbps
increments). Same as maximum train rate when using interleaving.
32-512000
128000 ‡
Max Delay Downstream or upstream maximum allowed delay for
retransmission. (ms, in 1 ms increments).
1-63
20 ‡
Min Single High Impulse
Noise Event (symbols)
Downstream or upstream minimum impulse noise protection
against SHINE (symbols).
0-63
4 ‡
Single High Impulse Noise
Ratio (symbols)
Downstream or upstream Single High Impulse Noise Event
(SHINE) Ratio (NDR, in .001 increments). As stated in G.998.4,
this is expected to be set by the operator using empirical methods.
0.000-0.100
0.010 ‡
Min Repetitive Impulse
Noise (symbols)
Downstream or upstream minimum impulse noise protection
against REIN (symbols).
0-7
0 ‡
Inter-Arrival Time Repetitive
Impulse Noise (Hz)
Downstream or upstream Repetitive Impulse Noise (REIN) inter-
arrival time (Hz). This is how you indicate that REIN is caused by
60Hz AC or 50Hz AC.
100, 120-hz ‡
‡Default
To modify the advanced parameters in a DSL template
1. On the Navigation Tree, click E7, E3-48C, E5-48, or E5-48C.
2. Click Template > DSL.
3. In the Workarea, double-click the DSL template that you want to modify.
4. Click Advanced to access the basic level of parameters for the DSL template.
5. Reference the table above to configure the parameters.
6. Click Apply.
For CLI:
set dsl-template <name> advanced [ptm-override|ds-rate-adapt-
mode|us-rate-adapt-mode|ds-downshift-adapt-margin|ds-upshift-adapt-
margin|us-downshift-adapt-margin|us-upshift-adapt-margin|ds-
downshift-adapt-time|ds-upshift-adapt-time|us-downshift-adapt-
time|us-upshift-adapt-time|ds-enhanced-inp|us-enhanced-inp|atm-
header-compress]
