To create dial plan rule
1. On the Navigation Tree, click E-Series.
2. Click Profiles > Service > Dial Plan.
3. In the Work area, double-click the dial plan of which you want to add a rule.
4. In the menu, click Create > Dial Plan Rule.
5. In the Create Dial Plan Rule dialog box, do the following:
a. In the ID list, select the index value to use if different from the default rule of "1."
b. In the Pattern box, type the pattern string and rule string.
The pattern must start with ^ and end with |.
For allowed characters, refer to the above table.
6. Click Create.
For CLI:
add rule <p
-index> to
-dial-plan <p
-name> pattern <token>
delete dial-plan <name>
set dial
-plan <p
-name> [rule|name|digit
-short-timer|digit-long-timer]
show dial-plan [<name>]
Creating a SIP Gateway Profile
This topic describes how to create a SIP gateway profile that is assigned to a SIP gateway
service provisioned on a Voice port.
You can define a unique SIP Profile ONTs and E-series xDSL nodes, entering attributes for
both the Primary Proxy Server settings, Primary and Secondary DNS servers, as well as
Secondary Proxy Server settings if enabling SIP Server Redundancy using static host
provisioning.
Parameters
You can provision the following parameters for SIP gateway profiles:
Parameter Description Valid Options
Name* Name of the SIP profile. Any established SIP service profile
