183
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
For CLI:
set interface <dsl-port> [eth-svc|description|subscriber-
id|immediate-leave|igmp-max-rate|igmp-max-groups|dscp-p-bit-map|ip-
prec-p-bit-map|lacp-tunnel|eth-sec-profile|force-dot1x|admin-state]
Related topics
Mapping Layer 3 Priority Values to P-Bits (on page 96)
Creating an Ethernet Security Profile (on page 143)
Creating VLANs
Creating an IGMP profile (on page 119)
Creating a Data Service
This section describes how to create a data (Internet) service on an xDSL port, using the
Form option on the xDSL port services menu. You can create six (6) Ethernet Services on a
single xDSL port.
The Form option allows you to initially provision multiple services on the xDSL port in
one view.
The Table option allows you to provision additional single services, delete single services,
or update existing services.
Profiles referenced in service provisioning
When provisioning subscriber services on a VDSL2 card xDSL port, you set up information
that is common to multiple subscribers and maintained in profiles. Repeating the similar task
of subscriber service activation then consists of referencing the existing profiles and
sometimes providing subscriber-specific information to complement the profiles.
Both service provision options allow you to activate services on an xDSL port and apply the
following previously-created profiles:
Ethernet Bandwidth Profile
Service Tag Actions
Note: When a profile is changed, all subscribers using that profile are affected. Profiles
cannot be deleted while they are in use. Profiles can also be reloaded for a specific VDSL2
xDSL port from the Port Services Table by clicking Refresh.
Information you need
At a minimum, you should have the following information on hand to configure xDSL data
service:
Ethernet bandwidth profile to use on the xDSL port
Service tag action ID to use for the data service
Tag ID(s) to apply, if "specify in service" was selected in the service tag action
