Multicast video profiles:
A video service is identified by the presence of a service definition, referencing a multicast
profile. The multicast profile defines the following attributes of a video service.
ï‚Ÿ Maximum number of simultaneous streams on subscriber port.
Multiple video profiles will typically differ in the number of streams allowed. A small number
of video profiles will be created and applied to many subscriber ports. For example, bronze,
gold, and platinum video services.
IGMP profiles:
Defines a profile for VLAN association that sets configuration attributes of the Internet
Group Management Protocol (IGMP) snoop used to establish membership in a multicast
video services group.
SIP Gateway Voice profiles:
Specifies the SIP service configuration information that previously resided in a SIP
configuration file in a primary and a secondary location.
TDM Voice Gateway profiles:
Specifies the port numbers for the UDP control plane traffic, and RTP voice traffic, as well
as the IP address of the C7 viper card.
H.248 Gateway profiles and H.248 Gateway:
Specifies the H.248 gateway properties for the VDSL2 H.248 gateway services.
IP host profiles:
The IP host profiles define attributes for static IP hosts, and are used for SIP and TDM
gateway services. It defines how the service obtains an IP address for communication.
Grade of Service (GOS) profiles:
Specifies reporting thresholds for certain monitored attributes of an xDSL port. For
example, any time a particular count exceeds a specified threshold within a certain period
(either 15 minutes or one day), a threshold-crossing alert is generated. For information on
creating the profile, see the Calix E7 Maintenance and Troubleshooting Guide or the E3-48/E5-
48/E5-48C User Guide.
