Creating VLANs
Creating an IGMP profile (on page 119)
Creating a Video Service
This section describes how to create a video service on an xDSL port, using the Form option
on the xDSL port services menu. You can create six (6) Ethernet Services on a single xDSL
port.
The Form option allows you to initially provision multiple services on the xDSL port in
one view.
The Table option allows you to provision additional single services, delete single services,
or update existing services.
Profiles referenced in service provisioning
When provisioning subscriber services on a VDSL2 card xDSL port, you set up information
that is common to multiple subscribers and maintained in profiles. Repeating the similar task
of subscriber service activation then consists of referencing the existing profiles and
sometimes providing subscriber-specific information to complement the profiles.
Both service provision options allow you to activate services on an xDSL port and apply the
following previously-created profiles:
Multicast Profile
Ethernet Bandwidth Profile
Service Tag Action
Note: When a profile is changed, all subscribers using that profile are affected. Profiles
cannot be deleted while they are in use. Profiles can also be reloaded for a specific VDSL2
xDSL port from the Port Services Form or Table by clicking Refresh.
Information you need
At a minimum, you should have the following information on hand to configure xDSL video
service:
Multicast profile to use for the video service
Ethernet bandwidth profile to use on the xDSL port
Service tag action ID to use for the video service
Tag ID(s) to apply, if "specify in service" was selected in the service tag action
Multicast white list (optionally)
