set dsl-template bp_data advanced ptm-override auto ds-rate-adapt-
mode dynamic us-rate-adapt-mode dynamic ds-downshift-adapt-margin 2
ds-upshift-adapt-margin 6 us-downshift-adapt-margin 2 us-upshift-
adapt-margin 6 ds-downshift-adapt-time 30 ds-upshift-adapt-time 30
us-downshift-adapt-time 30 us-upshift-adapt-time 30 ds-enhanced-inp
phyr us-enhanced-inp phyr atm-header-compress enabled
set dsl-template bp_video basic service-type vdsl2 vdsl-profile 17a
description bp_video ds-min-rate 384 ds-max-rate 100000 us-min-rate
384 us-max-rate 100000 ds-min-inp 2 us-min-inp 0.5 ds-intrlv-max-
latency 8 us-intrlv-max-latency 5 ds-min-snr 2 ds-max-snr 16 ds-
target-snr 8 us-min-snr 2 us-max-snr 16 us-target-snr 8 admin-state
enabled
set dsl-template bp_video advanced ptm-override auto ds-rate-adapt-
mode dynamic us-rate-adapt-mode dynamic ds-downshift-adapt-margin 5
ds-upshift-adapt-margin 9 us-downshift-adapt-margin 5 us-upshift-
adapt-margin 9 ds-downshift-adapt-time 30 ds-upshift-adapt-time 30
us-downshift-adapt-time 30 us-upshift-adapt-time 30 ds-enhanced-inp
phyr us-enhanced-inp phyr atm-header-compress enabled
Creating an Ethernet Security Profile
This topic shows you how to create an Ethernet security profile that is applied to xDSL port
interfaces to enable and/or specify security attributes of the port.
Note: The E-Series implementation of security profiles applies to non-TLAN services only.
For TLAN services, the L2CP Filter parameter must be set to all-tunnel.
Layer 2 Control Protocol (L2CP) handling
The E-Series supports provisionable Layer 2 Control Protocol (L2CP) handling (tunnel,
discard) on xDSL port interfaces and VLANs on the interface. The L2CP filtering is an
MEF-driven requirement for business services that use BPDU tunneling. The L2CP feature
supports per subscriber port configuration options to pass or discard the following L2CP
protocols:
Bridge Block of protocol frames with destination MAC addresses 0x01:80:c2:00:00:00
through 0x01:80:c2:00:00:0f.
GARP Block of protocol frames with destination MAC addresses 0x01:80:c2:00:00:20
through 0x01:80:c2:00:00:2f.
All LANs Bridge Management Group protocol frames with destination MAC address
0x01:80:c2:00:00:10.
Parameters
You can provision the following parameters for Ethernet security profiles:
Parameter Description Valid Options
Name* Name of the security profile. up to 32 character string
