172
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
To create a CMS TDM gateway service group
1. On the Navigation Tree, click CMS.
2. Click System > TDM Service Group.
3. In the menu, click Create.
4. Reference the table above to configure the parameters.
5. Click Create to save the service group.
Apply a TDM gateway service group when you create a TDM voice service on an E7 system
via CMS.
Creating an H.248 Gateway Profile
This topic describes how to create a profile that specifies the H.248 gateway properties for
the VDSL2 H.248 gateway services.
Note: The ‘Primary Gateway Controller’ and ‘Secondary Gateway Controller’ parameters
must be configured with a fully qualified domain name, when the IP host for H.248 services
is provisioned using Fully Qualify Domain Name (FQDN).
Parameters
You can provision the following parameters for H.248 gateway profiles:
Parameter Description Valid Options
Name* Name of the H.248 gateway profile. A 31-character text string
Base RTP Port Base port number for RTP packets. 49152 ‡ to 65535
Primary Gateway
Controller
IP address or hostname of the primary H.248 gateway controller, that is,
the softswitch.
text string
Primary Switch Type Type of voice soft switch.
h248-ansi-generic - softswitch type set to H.248 ANSI Generic
none - softswitch type not specified
cs-2000 - Nortel Communication Server 2000
cs-1500 - Nortel Communication Server 1500
metaswitch - Metaswitch softswitches
sonus - Sonus softswitches
genband-g2 - GENBAND G2 Compact Gateway
genband-g9 - GENBAND G9 Converged Gateway
taqua - Taqua softswitches
