Calix E3-48C User Manual

170
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Parameter Description Valid Options
RTP DSCP DSCP value for RTP packets.
 0-63 - DSCP for RTP packets
 cs0 - DSCP CS0 (0)
 cs1 - DSCP CS1 (8)
 af11 - DSCP AF11 (10)
 af12 - DSCP AF12 (12)
 af13 - DSCP AF13 (14)
 cs2 - DSCP CS2 (16)
 af21 - DSCP AF21 (18)
 af22 - DSCP AF22 (20)
 af23 - DSCP AF23 (22)
 cs3 - DSCP CS3 (24)
 af31 - DSCP AF31 (26)
 af32 - DSCP AF32 (28)
 af33 - DSCP AF32 (30)
 cs4 - DSCP CS4 (32)
 af41 - DSCP AF41 (34)
 af42 - DSCP AF41 (36)
 af43 - DSCP AF43 (38)
 cs5 - DSCP CS5 (40)
 ef - DSCP EF (46) ‡
 cs6 - DSCP CS6 (48)
 cs7 - DSCP CS7 (56)
RTP Ethernet QoS Ethernet QoS for RTP packets. 0-7
6 ‡
DHCP Filter Whether to use the server IP address as the DHCP offer
filter. When enabled, if the associated IP-host is using
DHCP, then the DHCP offer from the specific server will
be accepted.
enabled (selected), disabled (unselected)
‡
*Required field
‡ Default
To create a TDM voice gateway profile
1. Access the profile page:
 From CMS:
 On the Navigation Tree, click CMS.
 In the Work Area, click Profile > E3-48C/E5-48/E7/ONT > Profile >
Service > TDM GW.
 Locally on the E-Series:
 On theNavigation Tree, click the unit.
 In the Work Area, click Profiles > Service > TDM GW > Profiles.
2. In the menu, click Create.
3. Reference the table above to configure the parameters.
4. Click Create to save the profile.
