168
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Parameters when managing configuration files
Parameter Description
Source FTP Server* The IP address of your FTP server.
Source User* Username required by your FTP server.
Source Password* Password required by your FTP server.
Source File Path* File path of the configuration file on your FTP server.
Config Name* A configuration name instance is mapped to a retrieved DSL Configuration file, whose
contents will be applied to all DSL ports on the VDSL2 card.
Each VDSL2 card supports 2 VoIP configuration files (1 applied and 1 not-applied) for a
total of 4 VoIP configuration files per system.
The configuration name specified in the Retrieve/Apply DSL Configuration File operation
must match the configuration file instance specified in the IP Host. A configuration name
is specified by instance number alone or by “voip-<1 through 4>.”
voip-1 - Instance for VOIP (1)
voip-2 - Instance for VOIP (2)
voip-3 - Instance for VOIP (3)
Version* The version number of the DSL configuration file <x.x.x.x>. Typically, the version string is
the first line in the configuration file.
Note: The VDSL2 card will not download a new configuration file, unless the version
Force Select the Force box to force the system to retrieve and name the file as specified.
*Required field
To manage configuration files
1. On the Navigation Tree, click a VDSL2 card.
2. In the Work Area, click DSL Configuration > Action.
3. Select one of the actions, described in the table above:
Retrieve
Apply
Remove
4. Click the appropriate confirmation to invoke the action.
For CLI:
retrieve dsl-config
apply dsl-config
remove dsl-config
cancel dsl-config
reset card
