Calix E3-48C User Manual

152
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
 Once the bonding group has been configured, the subscriber service provisioning is on
the group interface.
The following table shows the settings that cause the bonding scheme to be
indeterminate.
Service Type PTM
Overrid
e
Bonding
Scheme
Result
VDSL2/ADSL2+
or VDSL2MM or
Auto
ATM Indeterminate If the line trains in VDSL2 mode, it uses PTM-TC. If the line trains in a
ADSL2/2+ mode, it uses ATM-TC. Therefore, the scheme is
indeterminate at provisioning time.
VDSL2/ADSL2+
or VD
SL2MM or
Auto
PTM PTM If the line trains in VDSL2 mode, it uses PTM-TC. If the line trains in
ADSL2/2+ mode, it is forced to use PTM-TC.
VDSL2/ADSL2+
or VDSL2MM or
Auto
Auto Indeterminate If the line trains in VDSL2 mode, it uses PTM-TC. If the line trains in
an ADSL2/2+ mode, it could use ATM-TC or PTM-TC.
VDSL2
X
PTM
VDSL2 always uses PTM-TC.
Anything else ATM ATM The line is provisioned as some kind of ADSL2/2+, and the line is
forced to use ATM-TC.
Anything else PTM PTM The line is provisioned as some kind of ADSL2/2+, and the line is
forced to use PTM-TC.
Anything else Auto Indeterminate The line is provisioned as some kind of ADSL2/2+, and the line could
use ATM-TC or PTM-TC.
Parameters
You can provision the following parameters for a DSL bonding group:
Parameter Description Valid Options
Name*
Name of the xDSL bonding group.
text string
Admin State
Service state of the bonding group.
enabled ‡, disabled
Subscriber ID Subscriber ID information, such as phone number, or account
number.
text string
(blank) ‡
Description Description of the DSL bonded interface, such as the subscriber
address, name, or service.
text string
(blank) ‡
IGMP Immediate
Leave
Whether a multicast stream is dropped as soon as a Leave is
received. The parameter is also set in the IGMP profile that is
associated with a VLAN. Setting the parameter at the bonding
group level overrides the setting in the IGMP profile.
enabled, disabled, use-
vlan-setting
DS Min Rate Downstream minimum rate in Kbps. Bonding group rates are
controlled by the underlying port rates. The DS/US Min Rate
parameters on groups are only used to generate low-rate alarms.
If you configure these to some value between the single-port rate
and bonded link rate, you will get a LOW RATE alarm on the group
when one port goes down. These values are not related to physical
train up rates or bandwidth profiles.
1-512000
US Min Rate Upstream minimum rate in Kbps. Bonding group rates are
controlled by the underlying port rates. The DS/US Min Rate
parameters on groups are only used to generate low-rate alarms.
If you configure these to some value between the single-port rate
and bonded link rate, you will get a LOW RATE alarm on the group
when one port goes down. These values are not related to physical
train up rates or bandwidth profiles.
1-512000
Security Profile
Name of the Security Profile to use.
text string
