Calix E3-48C User Manual

174
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
 Locally via the EWI:
 On the Navigation Tree, click the E7, E5-48 or E3-48C.
 In the Work Area, click Profiles > Service > H.248 GW > Profiles.
2. In the menu, click Create.
3. Reference the table above to configure the parameters.
4. Click Create.
For CLI:
create h248-gw-profile <p-name> [rtp-base-port|pri-gw-controller|pri-switch-
type|sec-gw-controller|sec-switch-type|term-prefix|ephemeral-term-id|esa-
mode|rtp-codec|packet-rate|country-code]
Creating an H.248 Gateway
This topic describes how to create a profile that specifies the H.248 gateway properties for
the VDSL2 H.248 gateway services.
Parameters
You can provision the following parameters for H.248 gateway:
Parameter Description Valid Options
Name* Name of the H.248 gateway. A 31-character text string
Admin State Administrative status for the gateway. enabled ‡, disabled
H.248 Gateway
Profile*
Name of the H.248 gateway profile. text string
IP Host*
Name of the line card IP Host.
text string
*Required field
‡Default
To create an H.248 Gateway
1. In the Navigation Tree, click the E-Series on which to create an H.248 Gateway.
2. In the Work Area, click H.248 Gateway, and then click Create.
3. Reference the table above to configure the parameters.
4. Click Create.
For CLI:
create h248-gw <shelf/card/gw-name> h248-gw-profile <p-name> ip-host <h-
name> [admin-state]
remove h248-gw-svc from-pots-port <vdsl-port>
