Video Recording Configuration: Video Format, Sensor Mode, System Frequency, Resolution and Frame Rate
60
Selecting the Sensor Mode
You can change the area of the imaging circle covered by the CMOS sensor to produce the recorded image.
1 Select > [Æ Recording/Media Setup] > [Sensor Mode].
• You can also adjust this setting using direct touch control (A 54).
2 Select the desired option.
Selecting the Main Recording Format
Select the combination of video format, color sampling and bit depth for primary clips.
1 Select > [Æ Recording/Media Setup] > [Main Rec Format].
• You can also adjust this setting using direct touch control (A 54).
2 Select the desired option.
Selecting the Resolution of Primary Clips
1 Select > [Æ Recording/Media Setup] > [Main Resolution].
• You can also adjust this setting using direct touch control (A 54).
2 Select the desired option.
Selecting the Frame Rate
Select the frame rate for the primary clips. This procedure is not necessary when the system frequency is set to
24.00 Hz.
1 Select > [Æ Recording/Media Setup] > [Frame Rate].
• You can also adjust this setting using direct touch control (A 54).
2 Select the desired option.
Selecting the Bit Rate for Primary Clips
Select the bit rate when the primary clip has the following recording format, resolution and frame rates.
1 Select > [Æ Recording/Media Setup] > [Bit Rate].
• Operation by direct touch control is also possible (A 54).
2 Select the desired option.
Main recording format Main resolution Frame rate Bit rate
XF-AVC YCC422 10bit
XF-AVC S YCC422 10bit
4096x2160 Intra-frame
3840x2160 Intra-frame
29.97P 600 Mbps, 450 Mbps, 300 Mbps
25.00P 500 Mbps, 375 Mbps, 250 Mbps
24.00P 480 Mbps, 360 Mbps, 240 Mbps
23.98P 480 Mbps, 360 Mbps, 240 Mbps
XF-AVC YCC422 10bit 1920x1080 Long GOP 59.94i, 50.00i 50 Mbps, 25 Mbps
