81
Focus
• Peaking cannot be displayed under the following conditions.
- When [OSD Output: SDI] or [OSD Output: HDMI] is set to [Off (Clean)] or [Off].
One-Shot AF
In this focus mode, you will focus manually in most situations but still have the option to have the camera focus
automatically only once on the subject inside the AF frame. You can change the type and position of the AF
frame.
1 Set the focus mode on the lens to automatic (A 78).
2Assign an assignable button to [One-Shot AF].
3 If necessary, change the type and position of the AF frame (A 83).
4Press and hold the assigned button.
• As long as the assigned button is held down the camera will focus automatically.
• When correct focus has been achieved, a green frame is displayed.
• If [Continuous AF] is disabled and [Subject to detect] is set to [None], the AF frame will disappear when you
release the assigned button (after a certain time has passed).
Continuous AF
The camera will focus automatically on a subject inside the area of the selected AF frame position/type (A 83).
For details on compatible lenses, refer to Compatible Lenses and Functions (A 242).
1 Set the focus mode on the lens to automatic (A 78).
2 Select > [
v
Camera Setup] > [Continuous AF] > [Enable].
• A white AF frame will appear on the screen (if the AF frame type is set to an option other than [Whole Area]).
• When focusing nearer is not possible, the AF frame will turn red.
• If [Lens action if cannot AF] was set to [Stop], when distance measurement is not possible, the AF operation
is stopped, the focus position is fixed and the AF frame becomes yellow.
3 If necessary, change the type and position of the AF frame (A 83).
Subject Tracking Adjustment After Focus
After focusing manually on the desired subject, you can automatically track the subject using the [Track after
Focusing] function. When there is no subject in focus, subject tracking is not performed and the AF operation is
performed on the automatically detected subject. Available when Continuous AF is enabled.
1 Select > [
v
Camera Setup] > [Track after Focusing] > Desired option.
2 Turn the focus ring to adjust as needed.
Options for [Track after Focusing]:
[On (tracking frame)]:
An orange frame for trackable subjects is displayed on the screen during focus operation. After
the focus operation, the frame changes to a white double frame £ (tracking frame) to perform
subject tracking.
[On (no tracking frame)]:
No frame for trackable subjects is displayed during focus operation. After the focus operation, a
white double frame £ (tracking frame) is displayed to perform subject tracking.
[Disable]: The subject is not tracked.
To Next Page
