Aperture
Aperture
You can affect the brightness of your recordings or change the depth of field by adjusting the aperture.
Depending on the lens used, the aperture value displayed may differ (F value or T value) and available aperture
values will vary as well (A 242). You can select the adjustment increment and even use the smallest iris
increment allowed by the lens.
You can also perform this function remotely using Browser Remote on a connected network device (A 184).
Manual aperture: Adjust the aperture value manually.
Automatic aperture: The camera adjusts the aperture automatically.
Push Auto Iris: Momentary automatic aperture. During manual aperture, press the AUTO IRIS button to
temporarily adjust the aperture automatically (only while the button is held pressed down).
Aperture Settings of the Lens
To adjust the aperture from the camera, you will need to enable automatic adjustment using the controls on the
compatible EF Cinema/broadcast/RF (with iris ring) lens. Required settings vary depending on the lens. Refer to
the instruction manual of the lens used.
Set the lens or iris ring to automatic aperture.
Manual Aperture: Changing the Aperture Value
1 Select > [
v
Camera Setup] > [Iris Mode] > [Manual].
• This setting is available only when a lens compatible with automatic aperture is attached to the camera. For
non-compatible lenses, the aperture mode is automatically set to [Manual] and cannot be changed.
2 When using a lens equipped with aperture settings, set the lens to automatic aperture mode.
3 Select > [
v
Camera Setup] > [Iris Increment] > [1/2 Stop] or [1/3 Stop].
• You can also set > [
v
Camera Setup] > [Fine Increment] to [On] to use the smallest iris increment
allowed by the lens attached. Nevertheless, the aperture value displayed on the screen will be the closest
value in the selected increment scale.
4Adjust the aperture value using direct setting mode (A 55).
• You can also use direct touch control (A 54).
