Canon EOS C80 - Displaying False Color

Onscreen Markers, Zebra Patterns and False Color
92
Displaying False Color
In CAMERA mode, you can display the false color overlay to check the brightness levels as different colors.
Select > [ A Assistance Functions] > Desired [False Color:] setting > [On].
• You can also use direct touch control (A 54) to turn the [False Color: LCD] setting on/off.
• Alternatively, you can press an assignable button (A 123) set to one of the [False Color:] settings to turn the
false color overlay on and off on the corresponding output destination.
NOTES
NOTES
• You can use the > [ A Assistance Functions] > [False Color Index] setting to check an index (in
English only) of the colors used in the false color overlay.
• Depending on the custom picture file settings, the color displayed might not be that of the correct brightness
level.
• [False Color: SDI] cannot be displayed under the following conditions.
- When [Sensor Mode] is set to [Full Frame] or [Super 35mm (Cropped)], the slow & fast motion recording
frame rate exceeds 60P and [SDI Output Signal] is [3840x2160] or higher.
- When [OSD Output: SDI] is set to [Off (Clean)].
• [False Color: HDMI] cannot be displayed under the following conditions.
- When [OSD Output: HDMI] is set to [Off].
Color Meaning
Red White clipping
Yellow Just below white clipping
Pink One stop over 18% gray
Green 18% gray (medium gray)
Blue Just above black clipping
Purple Black clipping
