Onscreen Markers, Zebra Patterns and False Color
90
2 For [Center Marker] only: Select > [ A Assistance Functions] > [Center Marker Type] > Desired marker
shape.
Aspect Marker
1 Select > [
A Assistance Functions] > [Aspect Marker] > Desired marker color or transparency of the
masked area.
• Select [Off] to turn off the marker.
2 Select > [
A Assistance Functions] > [Marker Aspect Ratio] > Desired option.
3 For [Custom] only: Select > [
A Assistance Functions] > [Marker Custom Asp. Ratio] and enter the
aspect ratio using the data entry screen (A 27).
NOTES
NOTES
Aspect markers will not be displayed in the following cases.
- When the resolution is set to 3840x2160 or 1920x1080 and the marker aspect ratio is set to [16:9].
- When the resolution is set to 4096x2160 or 2048x1080 and the marker aspect ratio is set to [1.90:1].
- The same applies when the same aspect ratio is set manually using [Custom].
Safe Area Marker
The safe area is displayed using a border line or by masking the image outside the safe area. It can be calculated
as a percentage of the width/height.
1 Select > [
A Assistance Functions] > [Safe Area Marker] > Desired marker color/mask opacity level.
• Select [Off] to turn off the marker.
2 Only when an aspect marker is already activated: Select > [ A Assistance Functions] > [Basis for
Marker Safe Area] > [Whole Picture] or [Selected Aspect Marker].
3 Select > [
A Assistance Functions] > [Marker Safe Area %] > Desired percentage.
• You can select the margin as a percentage of the width/height [(Side Length)].
User Markers
You can set 3 individual user markers ([User Marker 1] to [User Marker 3]) and adjust their color, size and position
separately.
1 Select > [ A Assistance Functions] > [User Marker 1], [User Marker 2] or [User Marker 3] > Desired
marker color.
• Select [Off] to turn off the marker.
2 Select > [
A Assistance Functions] > [User Marker 1 Settings], [User Marker 2 Settings] or [User
Marker 3 Settings] > [Size] > [Specification Method] > Desired option.
Options:
[Pixel]: Specify the number of pixels (width and height).
[Ref. Area & Aspect Ratio]:
Specify an aspect ratio for the reference area.
[Ref. Area & Magn. Ratio]:
Specify a magnification ratio for the selected reference area.
• Select the input value or setting value according to the selected specification method.
3 Select > [
A Assistance Functions] > [User Marker 1 Settings], [User Marker 2 Settings] or [User
Marker 3 Settings] > [Position] > [Specification Method] > Desired option.
