CHAPTER 6 IMAGE FORMATION SYSTEM
6-2
■ High voltage related output sequence
Conditions: When copying 2 sheets of A4 size paper.
Figure 6-102
INTR1
STBY INTR2 SCFW
SCRV
SCFW
SCRV
LSTR STBY
Main motor (M601)
Fixing heater
Document scanner motor (M701)
Scanner HP sensor (PS101)
Scanning lamp
Cassette pick-up solenoid (SL301)
Pick-up vertical path clutch (CL301)
Pick-up sensor (PS303)
Registration clutch (CL302)
Registration sensor (PS302)
Paper leading edge sensor (PS301)
Primary charging roller bias DC component
Primary charging roller bias AC component
Transfer charging roller bias
Separation static charge eliminator bias
Developing bias DC component
Developing bias AC component
Power ON
Start key ON
160˚C control150˚C control
forward
backward
negative bias
negative bias
Paper interval bias
Paper interval bias
Re-charging bias
