CHAPTER 3 EXPOSURE SYSTEM
3-2
B. Exposure system sequence
Figure 3-103
Document scanner
motor (M701)
Scanner home
position sensor (PS101)
Scanning lamp
Start
key ON
STBY INTR SCFW
SCRV
SCRV
SCFW
LSTR
STBY
