CHAPTER 1 MAINTENANCE AND SERVICING
1-2
B. ADF
1. Periodic replacement parts
There are no parts in the unit that need to be periodically replaced.
2. Consumables replacement targets
These parts may require replacement once or more during the warranty period due
to deterioration or damage. The expected life (number of pages) of parts that do not
need to be replaced until they fail is indicated below.
As of January, 1999
Table 1-2
No.
1
2
3
Part Name
Pick-up roller/
separation roller
Friction bar
Stamp unit
Part No.
HG5-1652-000
FG6-1303-000
HH7-2206-000
Quantity
1
1
1
Expected life span
50,000 sheets
50,000 sheets
100,000 sheets
Remarks
The information in the table above is not unit counter data but the actual number of
sheets. It is only an estimate, and may be revised in the light of empirical data.
Caution:
