CHAPTER 13 TROUBLESHOOTING
13-34
III.FAULTY FEEDING COUNTERMEASURES
A. Overview
The primary locations where paper jams occur in this machine are as shown below.
[1] Pick-up assembly
[2] Feeder assembly
[3] Fixing/Delivery area
Figure 13-301
Reference:
The figure above depicts a machine with a 3-level cassette feeder. The feeder con-
struction is the same on all levels. Accordingly, when only one cassette feeder level is
attached, the structure will be like the figure above with the bottom two levels
removed.
[1]
[2]
[3]
