CHAPTER 9 EXTERNAL/AUXILIARY MECHANISM
9-2
II. POWER SUPPLY
A. Low-voltage power supply circuit
1. Low-voltage power supply circuit
The DC power supply of the main unit is generated by the DC power supply PCB.
The DC power supply PCB converts the input AC power supply into DC+24V,
DC+12V, DC-12V, and DC+5V, and supplies each of the internal electrical loads.
An overview of the DC power supply is shown in the table below.
Table 9-201
Ratings for the fuses installed on the DC power supply PCB
Table 9-202
Output voltage name Output voltage value
+5V1 and +5V2 +5.1V ± 3%
+12V +12.0V ± 5%
-12V -12.0V ± 5%
+24V1 and +24V2 +24.0V ± 5%
Electrical symbol Rating
F1 15A 125V
F2 15A 125V
F3 5A 125V
F4 5A 125V
