CHAPTER 13 TROUBLESHOOTING
13-52
2. DC controller PCB/ Sensor PCB
■ DC controller PCB
Figure 13-407
VR402: For factory adjustment
■ Sensor PCB
Figure 13-408
VR401 : VR for image leading edge margin adjustment
SW401 : Push switch for test print output
J311
VR402
J302 J310
J301
J305
J308
J307
J306
J303
T406
T403
JH401
JH402 JH406
JH407
J309
J304
J401
SW401
VR401
