COPYRIGHT
©
1999 CANON INC. CANON GP160 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 8 FIXING SYSTEM
8-2
Figure 8-102
M601
DC Power supply
PCB
DC controller PCB
Fixing heater
Pressure roller
Delivery roller
Delivery
sensor
(PS306)
Main
motor
Motor drive signal (MMD)
Delivery signal (PS306S)
Heater drive (FSRDRV)
Cleaning roller
