CHAPTER 13 TROUBLESHOOTING
13-45
Sensors
Table 13-403
Symbol Code Function
PS101 Scanner home position sensor
PS102 Copyboard cover open/close sensor
PS301 Paper leading edge sensor
PS302 Registration paper sensor
PS303 Pick-up sensor
PS304 Paper width sensor
PS305 Cassette paper supply sensor
PS306 Delivery sensor
PS501 Multifeeder paper supply sensor
PS651 Cassette feeder pick-up sensor
PS652 Cassette paper supply sensor (cassette feeder)
Name
Photo-
interuppter
To Next Page
