CHAPTER 13 TROUBLESHOOTING
13-112
2. Test Mode menu
To operate the test mode, press the enter/set key then the # key and select the SER-
VICE MODE. Then use the up/down shift keys to select TEST MODE and depress the
set key.
After finishing the TEST MODE, press the stop key, then the clear key.
Figure 13-509
1: D-RAM
[1] - - - [2]
TEST MODE [1] - [7], [9]
E40 :
******
2: CCD TEST
[1] - - - [8]
3: PRINT
[0] - - - [9] , [*] , [#]
3: PRINT 3-
1: WHITE
3: PRINT
3-2: BLACK
3: PRINT
3-3: STRIPES
3: PRINT
3-4: CHECKERS
3: PRINT
3-5: CHECKERS-2
3: PRINT
3-6: ENDURANCE
3: PRINT
3-7: BLACK/WHITE
3: PRINT
3-0: AMI PATERN
3: PRINT
3-9: CHECKERS-3
1: D-RAM 7168K
1: D-RAM 7168K
******
3: PRINT
3-8: BIAS
3: PRINT
3-*: PRINTING AREA
3: PRINT
3-#: CRG TEST
