CHAPTER 13 TROUBLESHOOTING
13-162
*1: Service error code
*2: START TIME: Date and time (displays in 24 hour mode)
*3: OTHER PARTY: Telephone number sent from the other party
*4: MAKER CODE: Manufacturer code
*5: MACHINE CODE: Code by machine type
*6: V.8 signal code contents received from the other party’s machine
*7: Symbol speed used by primary channel
*8: Data speed used by primary channel
*9: 0 (fixed)
*10:Code output by modem when transaction ends in error (do not use in service)
*11:Modem transmission status when transaction ends in error (do not use in service)
*12:Modem reception status when transaction ends in error (do not use in service)
*13:Received DIS, DCS or DTC bit1-48
*14:Transmitted DIS, DCS or DTC bit1-48
*15:RX= Received protocol signal
TX= Transmitted protocol signal
To Next Page
