D LIST OF SPECIAL TOOLS
The following are special tools used to service to copier: use them in addition the
standard set of tools.
*Consult the following for a stocking idea.
A: Each service person is expected to carry one.
B: Each group of five service persons is expected to carry one.
C: Each workshop is expected to carry one.
No. Tool Name Remarks
1 Digital
Multimeter
Tool No.
FY9-2002-000
Shape Rank
A Use it to check
the power.
2 Door switch
acutuator
TKN-0093 A
3 Mirror positioning
tool (front, rear)
FY9-3009-040 B For adjusting the
distance
between No.1
and No.2 mirror
mounts.
4 Pulley clip FY9-3010-000 C Scanner wire
adjustment
To Next Page
