4-58
CHAPTER 4 SERVICE MODE
Figure 4-10
4: MODEM NCU
[1] - - - [8]
4-1. RELAY
[1] - - - [2]
RELAY 1
[0] - - - [5]
RELAY 1 100000
1-0: CML ON
RELAY 1 010000
1-1: P ON
RELAY 1 001000
1-2: S ON
RELAY 1 000100
1-3: H ON
RELAY 1 000010
1-4: D ON
RELAY 1 000001
1-5: R ON
RELAY 2 100000000
2-0: CMP ON
RELAY 2 010000000
2-1: NZ ON
RELAY 2 001000000
2-2: CI1 ON
RELAY 2 000100000
2-3: CI2 ON
RELAY 2 000010000
2-4: AST ON
RELAY 2 000001000
2-5: C1 ON
RELAY 2 000000100
2-6: C2 ON
RELAY 2 000000010
2-7: NOR ON
RELAY 2 000000001
2-8: DC ON
RELAY 2
[0] - - - [8]
