FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
100 - 5 E FB4-5598-000 1 LABEL, JAM CLEARING GERMANY
6 FB4-5579-040 1 COVER, LEFT 100V
FB4-5837-000 1 COVER, LEFT 120/230V
7 XA9-0605-000 2 SCREW,P,M4X8
8 FB4-5580-030 1 PLATE, DELIVERY TRAY 100V
FB4-5842-000 1 PLATE, DELIVERY TRAY 120/230V
9 FB4-5572-000 1 COVER, LEFT 100/120V,GP160
FB4-5846-000 1 COVER, LEFT GP160PF
10 FB4-5586-000 2 COVER, FEEDER, LEFT
11 XA9-1041-000 4 SCREW, RS, M4X10
12 FB3-2224-000 2 PIN, HINGE
13 FB4-5571-000 1 COVER, RIGHT
14 FB4-5573-000 1 COVER, FRONT
15 FB4-5591-000 1 COVER, OPERATION, LOWER LP3000
FB4-5840-000 1 COVER, OPERATION, LOWER 120V NLU
FB4-5771-000 1 COVER, OPERATION, LOWER 230V/LP3010
120V NLV/NNF
16 FB4-5575-000 1 COVER, RIGHT
17 FB4-5577-000 1 COVER, READER, RAER
18 FB4-5582-000 1 TRAY 100/120V
FB4-5844-000 1 TRAY 230V
19 FB4-5404-000 1 HOLDER, GLASS, RIGHT
20 XA9-0629-000 AR SCREW,RS,M4X8
21 FS1-9010-000 1 SCREW,STEPPED,M3X2.2
22 FF5-7258-000 1 GLASS, COPYBOARD AB SIZE
FF5-7284-000 1 GLASS, COPYBOARD INCH/A SIZE
FF5-7296-000 1 GLASS, COPYBOARD A SIZE
22 A FB4-5406-000 1 PLATE, LENGTH INDEX AB SIZE
FB4-5484-000 1 PLATE, LENGTH INDEX INCH/A SIZE
FB4-5485-000 1 PLATE, LENGTH INDEX A SIZE
22 B FB4-5407-000 1 PLATE, LENGTH INDEX AB SIZE
100-3
